Plastic PVC Angle Seat Check Valve 

Plastic PVC Angle Seat PVC Wafer Check Valve is installed on the pipeline to prevent the reverse flow, the PVC Swing Check Valve cap design is removable sealed with EPDM O ring.  Specification Material: UPVC Size:DN15,DN20,DN25,DN32,DN40,DN50,DN65,DN80 Seal:EPDM Connection:Socket, Flange, Thread Standard:DIN, ANSI, JIS Features 1. The PVC Wafer Check Valve disc moves up and down. The connecting pipe connects the upper chamber with the valve outlet. When PVC Check valve disc rises and falls down, the impact and vibration are reduced, and the valve disc reaches the full stroke 2.PVC Swing Check Valve body is Y-shaped, with small resistance and flexible disc operation 3. Pressure self tightening seal is adopted. The seal is reliable 4. The sealing surface of valve disc and valve seat is sealed with EPDM sealing ring, which is corrosion-resistant, scratch resistant and durable Dimension Sheet
