High Performance Physical Foaming Insulation Extruder

High Performance Physical Foaming Insulation Extruder   Designed for High-Frequency Cable Insulation Requirements   The High Performance Physical Foaming Insulation Extruder is developed for cable applications where insulation structure directly affects transmission quality. By introducing controlled gas into the insulation layer, this equipment helps reduce dielectric loss and improve cable performance while keeping the material usage efficient.  Parameter CZ Small Extruder φ12-φ28 CZ Medium Extruder φ30-φ45 CZ Large Extruder φ50-φ90 Model φ12 φ15 φ18 φ20 φ25 φ28 φ30 φ35 φ40 φ45 φ50 φ60 φ70 φ80 φ90 Extrusion Material FEP PFA ETFE XETFE Output Capacity 1.5kg/h to 12kg/h 15kg/h to 30kg/h 37kg/h to 160kg/h Finished Wire Range 0.08 to 1.4mm 0.25 to 10.0mm 5.0 to 35.0mm Production Speed 0 to 300 m/min 0 to 300 m/min 0 to 150 m/min Conductor Structure Single or stranded conductor Stranded wire and core Stranded wire and core Insulation Type Single co extrusion multi la…
